Leviton 4729-C
Leviton® Black & White® 4729-C 1-Phase Grounding Locking Connector, 125 VAC, 15 A, 2 Poles, 3 Wires, Black/White
Leviton 4729-C
Leviton® Black & White® 4729-C 1-Phase Grounding Locking Connector, 125 VAC, 15 A, 2 Poles, 3 Wires, Black/WhiteIn Stock: 20More Info
|
BrandLeviton
MFG #4729-C
Werner Part #45403
UPC078477795521
In Stock: 20More Info
|
BrandLeviton
MFG #4729-C
Werner Part #45403
UPC078477795521
Product Description
Leviton® Black & White® Locking Connector, 1-Phase Grounding, 125 VAC, 15 A, 1/2 hp, 2 Poles, 3 Wires, NEMA L5-15R, Industrial Grade, 0.24 to 0.7 in Cord Dia, -40 to 60 deg C, Screw Terminal, Nylon, Black/White, 1.53 in Dia x 2.76 in H
Attributes
Documents
Specifications
Attributes
Amperage Rating15
ColorBlack/White
Country of OriginUS
Dimensions1.53 in Dia x 2.76 in H
GradeIndustrial
Horsepower1/2 hp
ManufacturerLeviton
MaterialNylon
NEMA RatingNEMA L5-15R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeScrew
Type1-Phase Grounding
Type / Style1-Phase Grounding
Voltage Rating125 VAC
Documents
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C73|CSA C22.2 No.42 File No. LR406|NOM 057|NEMA WD1/WD6|UL 498 File No. E13393|Federal Specification WC596|UL94 V-2 Flammability Rating
