Leviton 2436
Leviton® V-0-Max™ 2436 3-Phase Grounding Receptacle Locking Flanged Outlet, 480 VAC, 20 A, 3 Poles, 4 Wires, White
Leviton 2436
Leviton® V-0-Max™ 2436 3-Phase Grounding Receptacle Locking Flanged Outlet, 480 VAC, 20 A, 3 Poles, 4 Wires, WhiteOut of StockMore Info
|
BrandLeviton
MFG #2436
Werner Part #1304693
UPC078477806340
Out of StockMore Info
|
BrandLeviton
MFG #2436
Werner Part #1304693
UPC078477806340
Product Description
Leviton® V-0-Max™ Locking Flanged Outlet, 3-Phase Grounding Receptacle, 480 VAC, 20 A, 5 hp, 3 Poles, 4 Wires, NEMA L16-20R, Industrial Grade, -40 to 60 deg C, Back Wired Terminal, Nylon, White, 2.5 in Dia x 1.78 in H
Attributes
Documents
Specifications
Attributes
Amperage Rating20
ColorWhite
Country of OriginUS
Dimensions2.5 in Dia x 1.78 in H
GradeIndustrial
Horsepower5 hp
ManufacturerLeviton
MaterialNylon
NEMA RatingNEMA L16-20R
Number of Poles3
Number of Wires4
Temperature Rating-40 to 60 deg C
Terminal TypeBack Wire
Type3-Phase Grounding Receptacle
Type / Style3-Phase Grounding Receptacle
Voltage Rating480 VAC
Documents
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C73|CSA C22.2 No.42 File No. LR406|NOM 057|NEMA WD1/WD6|UL 498 File No. E13393|UL94 V-2 Flammability Rating
Leviton® V-0-Max™ 2436 3-Phase Grounding Receptacle Locking Flanged Outlet, 480 VAC, 20 A, 3 Poles, 4 Wires, White
