Leviton 2415
Leviton® V-0-Max™ 2415 Grounding Receptacle Locking Flanged Inlet, 125/250 VAC, 20 A, 3 Poles, 4 Wires, White
Leviton 2415
Leviton® V-0-Max™ 2415 Grounding Receptacle Locking Flanged Inlet, 125/250 VAC, 20 A, 3 Poles, 4 Wires, WhiteOut of StockMore Info
|
Out of StockMore Info
|
Product Description
Leviton® V-0-Max™ Locking Flanged Inlet, Grounding Receptacle, 125/250 VAC, 20 A, 1 hp, 2 hp, 3 Poles, 4 Wires, NEMA L14-20P, Industrial Grade, -40 to 60 deg C, Back Wired Terminal, Nylon, White, 2.5 in Dia x 1.78 in H
Attributes
Documents
Specifications
Attributes
Amperage Rating20
ColorWhite
Country of OriginUS
Dimensions2.5 in Dia x 1.78 in H
GradeIndustrial
Horsepower1 hp, 2 hp
ManufacturerLeviton
MaterialNylon
NEMA RatingNEMA L14-20P
Number of Poles3
Number of Wires4
Temperature Rating-40 to 60 deg C
Terminal TypeBack Wire
TypeGrounding Receptacle
Type / StyleGrounding Receptacle
Voltage Rating125/250 VAC
Documents
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C73|CSA C22.2 No.42 File No. LR406|NOM 057|NEMA WD1/WD6|UL 498 File No. E13393|UL94 V-2 Flammability Rating|Federal Specification WC596
Leviton® V-0-Max™ 2415 Grounding Receptacle Locking Flanged Inlet, 125/250 VAC, 20 A, 3 Poles, 4 Wires, White
