Decora Plus 5380-IGI
Leviton® Decora® Plus 5380-IGI 2-Pole 3-Wire Type 3-Duplex Isolated Self-Grounding Surge Protective Receptacle, 125 VAC, 20 A, 5 kA SCCR
Decora Plus 5380-IGI
Leviton® Decora® Plus 5380-IGI 2-Pole 3-Wire Type 3-Duplex Isolated Self-Grounding Surge Protective Receptacle, 125 VAC, 20 A, 5 kA SCCROut of StockMore Info
|
Out of StockMore Info
|
Product Description
Leviton® Decora® Plus Surge Protective Receptacle, 2-Pole 3-Wire Type 3-Duplex Isolated Self-Grounding, 125 VAC, 20 A, 5 kA Short Circuit Current Rating, Straight Blade Receptacle Outlet, Indicators: Lights, Back/Side Wired, Surface, 3.81 in H x 1.7 in W x 1.47 in D, -40 to 60 deg C Operating, Polycarbonate, Ivory
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating20
ColorIvory
ConnectionBack/Side Wired
Country of OriginMX
ManufacturerLeviton
MaterialPolycarbonate
Mounting TypeSurface
Size3.81 in H x 1.7 in W x 1.47 in D
Temperature Rating-40 to 60 deg C / -40 to 60 deg C Operating Temperature, UL 94 V-2 Flammability Rated
Type2-Pole 3-Wire Type 3-Duplex Isolated Self-Grounding
Type / Style2-Pole 3-Wire Type 3-Duplex Isolated Self-Grounding
Voltage Rating125 VAC
Documents
Features
Tamper resistant versions have a shutter mechanism that prevents incidental contact with energized contactsIndicator light provides visual indication that equipment is being protectedEMI/RFI noise filteringWide variety of color options aid in identifying different types of equipment or applicationsBack and side wired design with durable metal mounting strapPoint of use protection for up to 18000 A of surge current totalL-N/L-G modes of protection720 J energy rating27 kA peak surge current
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|NEMA WD1/WD6|ANSI C73|UL 498/1449|CSA C22.2|NOM 057|UL94 V-2 Flammability Rating
Leviton® Decora® Plus 5380-IGI 2-Pole 3-Wire Type 3-Duplex Isolated Self-Grounding Surge Protective Receptacle, 125 VAC, 20 A, 5 kA SCCR
