Blackburn WR9
Thomas & Betts Blackburn® WR9 Type WR Wide Range Compression H-Tap Connector, H Shape, 6 to 3 AWG ACSR, 6 to 2 AWG Stranded, 4 to 1 AWG Solid Main/Run, 14 to 8 AWG Stranded, 14 to 8 AWG Solid Tap, Aluminum
Blackburn WR9
Thomas & Betts Blackburn® WR9 Type WR Wide Range Compression H-Tap Connector, H Shape, 6 to 3 AWG ACSR, 6 to 2 AWG Stranded, 4 to 1 AWG Solid Main/Run, 14 to 8 AWG Stranded, 14 to 8 AWG Solid Tap, AluminumOut of StockMore Info
|
Out of StockMore Info
|
Product Description
Blackburn® Compression H-Tap Connector, Type WR Wide Range, H, 6 to 3 AWG ACSR, 6 to 2 AWG Stranded, 4 to 1 AWG Solid Main/Run, 14 to 8 AWG Stranded, 14 to 8 AWG Solid Tap, ACSR/Aluminum/Copper/Solid/Stranded Conductor, 5/8 or BG Die Code 0.184 to 0.292 in Dia Main Conductor, 0.064 to 0.146 in Dia Tap Conductor, 2-Conductor, 90 deg C, Aluminum, 13/16 in L
Attributes
Documents
Features
Specifications
Attributes
Conductor TypeACSR/Aluminum/Copper/Solid/Stranded
Country of OriginMX
Dimensions13/16 in L
ManufacturerThomas & Betts
MaterialAluminum
SeriesWR Series
Temperature Rating90 deg C
TypeType H Wide Range
Type / StyleType WR Wide Range
Documents
Features
Made of 1350 aluminum alloy for high strength and high conductivityStandard compression tools and dies install all sizes no special tools neededField proven ribbed design enables excellent connector/conductor contact without distorting the conductor shapeFold-in tabs provide tab interlock as tool closesPrefilled with oxide inhibitor held captive in the rib/connection areaCompression/crimp connection
Specifications
5/8 or BG Die Code 0.184 to 0.292 in Dia Main Conductor, 0.064 to 0.146 in Dia Tap Conductor, 2-Conductor
