Blackburn 8H
Thomas & Betts Blackburn® 8H Type H High Strength Split Bolt Connector, 10 to 8 AWG Solid/Stranded Copper Conductor, 3/8 x 25/32 in, Bronze Alloy
Blackburn 8H
Thomas & Betts Blackburn® 8H Type H High Strength Split Bolt Connector, 10 to 8 AWG Solid/Stranded Copper Conductor, 3/8 x 25/32 in, Bronze AlloyProduct Description
Blackburn® Split Bolt Connector, Type H High Strength, Solid/Stranded Copper Conductor, 10 to 8 AWG Conductor, 3/8 x 25/32 in Bolt, 0.146 in Split, 1/2 in Hex Nut, Bronze Alloy, Metallic
Attributes
Documents
Features
Specifications
Attributes
ColorMetallic
Conductor size10 to 8 AWG
Conductor TypeSolid/Stranded Copper
Country of OriginMX
ManufacturerThomas & Betts
MaterialBronze Alloy
TypeType H High Strength
Type / StyleType H High Strength
Features
Bolt and nut of high-strength corrosion resistant bronze alloyPressure bar is copper through 40H, copper alloy for 350 kcmil and aboveBolt and nut of hex design up to 350 kcmilSplit-bolt connector made of metallic bronze alloy for use on copper conductors14 AWG solid conductor range min tap with one max main8 AWG stranded to 10 AWG solid conductor range for equal main and tap100 Pieces/Pack
Specifications
0.146 in Split, 1/2 in Hex Nut
