Leviton N1302-DS
Leviton® Powerswitch® N1302-DS Type 1 Grounding Industrial Grade Manual AC Motor Starter Switch, 600 VAC, 30 A, 15 hp Power Rating, DPST Contact
Leviton N1302-DS
Leviton® Powerswitch® N1302-DS Type 1 Grounding Industrial Grade Manual AC Motor Starter Switch, 600 VAC, 30 A, 15 hp Power Rating, DPST ContactOut of StockMore Info
|
Out of StockMore Info
|
Product Description
Leviton® Powerswitch® AC Motor Starter Switch, Type 1 Grounding Industrial Grade Manual, 600 VAC, 30 A, 15 hp, DPST, 30 A at 600 VAC Contact, 2 Pole, Toggle, NEMA WD-1/WD-6 Enclosure, Back/Side Wired Screw Terminal, 6000 Cycles Operating Cycles, Polyester, Gray, Environmental Conditions: -40 to 60 deg C Operating Temperature, 4.75 in H x 3.25 in W x 3.16 in D
Attributes
Documents
Features
Specifications
Attributes
Actuator TypeToggle
Amperage Rating30
ColorGray
ConnectionBack/Side Wire/Screw
Country of OriginMX
Dimensions3.25 in W x 3.16 in D x 4.75 in H
Electrical Ratings15 hp
Enclosure TypeNEMA WD-1/WD-6
ManufacturerLeviton
Mounting TypeNEMA WD-1/WD-6
Number of Poles2
Temperature Rating-40 to 60 deg C Operating Temperature
TypeType 1 Grounding Industrial Grade Manual
Type / StyleType 1 Grounding Industrial Grade Manual
Voltage Rating600 VAC
Documents
Features
All molded parts are thermoplastic to resist impacts, chemicals, temperature, tracking and arcingCam driven mechanism enhances fast make/slow breakSilver alloy contacts for maximum conductivity and service lifeInsulating barrier between terminals provide isolation between phasesNickel plated brass mounting strap, terminal screw and external clamps for superior strength and corrosion resistanceOversized toggle provides positive actuation, even with gloved hand
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C73|cUL per CSA C22.2 No. 111 (File E63969) Certified|NOM-ANCE Certified|UL 60947-4-1 Supersedes UL 508|UL94 V-0 Flammability Rating
