Appleton WSR6352
Emerson Electric AppletonĀ® WSR6352 Fused Grounding Style 2 Interlocked Receptacle With Enclosed Disconnect Switch, 600/250 VAC/VDC, 60 A, 4 Poles, 3 Wires
Appleton WSR6352
Emerson Electric AppletonĀ® WSR6352 Fused Grounding Style 2 Interlocked Receptacle With Enclosed Disconnect Switch, 600/250 VAC/VDC, 60 A, 4 Poles, 3 WiresBrandAppleton
MFG #WSR6352
Werner Part #3791808
UPC781381718042
BrandAppleton
MFG #WSR6352
Werner Part #3791808
UPC781381718042
Product Description
AppletonĀ® Interlocked Receptacle, Fused Grounding Style 2, Series: WSR, 600/250 VAC/VDC, 60 A, 15 /50 hp, 50/60 Hz Frequency, 4 Pole, 3 Wires, NEMA 3/3R/4/4X/12 NEMA, 6 to 2 AWG Wire, Copper Free Aluminum, 22.25 in H x 10.5 in W x 10.31 in D Dimensions
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating60
Country of OriginUS
Dimensions22.25 in H x 10.5 in W x 10.31 in D
Frequency Rating50/60 Hz
Horsepower15 /50 hp
ManufacturerEmerson Electric
MaterialCopper Free Aluminum
NEMA RatingNEMA 3/3R/4/4X/12
Number of Poles4
Number of Wires3
SeriesWSR
Size of Wire6 to 2 AWG
Type3-Phase Fused Grounding Style 2
Type / StyleFused Grounding Style 2
Voltage Rating600/250 VAC
Documents
Features
Shell and extra pole grounding style 2For use where an interlocked disconnect switch is desired to control a Powertite receptacle and insertion or removal of plugShort circuit withstand rated to 200000 RMS symmetrical ampsUnit is equipped with defeatable door interlock which allows emergency access when switch is energizedCover can be padlocked closedDead front design receptacle is not energized until plug is fully inserted and switch is engagedWithout viewing windowCorrosion resistant, raintight, watertight
Specifications
Standards/Approvals: ARRA Compliant|UL 98|UL 50E|UL 1682|UL 1686|UL File No. E145917|UL File No. E160652|CSA C22.2 No.4|C22.2 No. 182.1|CSA File No. 025875
