Leviton 2615
LevitonĀ® 2615 Grounding Receptacle Locking Flanged Inlet, 125 VAC, 30 A, 2 Poles, 3 Wires, White
Leviton 2615
LevitonĀ® 2615 Grounding Receptacle Locking Flanged Inlet, 125 VAC, 30 A, 2 Poles, 3 Wires, WhiteOut of StockMore Info
|
Out of StockMore Info
|
Product Description
LevitonĀ® Locking Flanged Inlet, Grounding Receptacle, 125 VAC, 30 A, 2 hp, 2 Poles, 3 Wires, NEMA L5-30P, Industrial Grade, -40 to 60 deg C, Back Wired Terminal, Nylon, White, 2.88 in Dia x 2.11 in H
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating30
ColorWhite
Country of OriginUS
Dimensions2.88 in Dia x 2.11 in H
GradeIndustrial
Horsepower2 hp
ManufacturerLeviton
MaterialNylon
NEMA RatingNEMA L5-30P
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeBack Wire
TypeGrounding Receptacle
Type / StyleGrounding Receptacle
Voltage Rating125 VAC
Documents
Features
Full rated current limitingRugged nylon flange fits flush and won't crack in high abuse applicationsIndividual deep funneled chamfered wire wells guide each wire into rectangular chambersWire clamps bundle stranded wire without cutting wire strandsRatings and NEMA ID permanently marked on device for identification
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C73|NOM 057|NEMA WD1/WD6|CSA C22.2 No.42 File No. LR406|Federal Specification WC596|UL 498 File No. E13393|UL94 V-2 Flammability Rating
