Sta-Kon PT70
Thomas & Betts Sta-Kon® PT70 Non-Insulated Wire Joint, 600 VAC, 14 to 12 AWG Wire, 0.34 in L, Steel
Sta-Kon PT70
Thomas & Betts Sta-Kon® PT70 Non-Insulated Wire Joint, 600 VAC, 14 to 12 AWG Wire, 0.34 in L, SteelBrandSta-Kon
MFG #PT70
Werner Part #64962
UPC786210803814
BrandSta-Kon
MFG #PT70
Werner Part #64962
UPC786210803814
Product Description
Sta-Kon® Wire Joint, Non-Insulated, Series: PT Series, 600 VAC, 14 to 12 AWG Wire, 0.34 in Length, 90 deg C, Steel, Metallic, Copper Plated, 0.29 in Dia Base Dimensions
Attributes
Documents
Features
Specifications
Attributes
ColorMetallic
Country of OriginUS
Dimensions0.29 in Dia Base
FinishCopper Plated
ManufacturerThomas & Betts
MaterialSteel
SeriesPT Series
Size of Wire14 to 12 AWG
Temperature Rating90 deg C
TypeNon-Insulated
Type / StyleNon-Insulated
Voltage Rating600 VAC
Documents
Features
Non-insulated crimp-on wire joint1-piece design1000 VAC for fixtures and signApplication tool WT161M(2)14 to (3)12 AWG
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL File No. E9809|CSA Certified
Thomas & Betts Sta-Kon® PT70 Non-Insulated Wire Joint, 600 VAC, 14 to 12 AWG Wire, 0.34 in L, Steel
