Sta-Kon RB14-250FP
Thomas & Betts Sta-Kon® RB14-250FP 250 Insulated Piggy Back Disconnect, 16 to 14 AWG Conductor, Brass/Copper, Blue
Sta-Kon RB14-250FP
Thomas & Betts Sta-Kon® RB14-250FP 250 Insulated Piggy Back Disconnect, 16 to 14 AWG Conductor, Brass/Copper, BlueProduct Description
Sta-Kon® Piggy Back Disconnect, Insulated, Series: 250, 16 to 14 AWG Conductor, 0.87 in Length, 600 VAC, 0.25 in x 0.032 in Tab Size, 0.163 in Maximum Insulation, 105 deg C, Brass/Copper, Blue, Tin Electro-Plated, 0.3 in W
Attributes
Documents
Features
Specifications
Attributes
ColorBlue
Conductor size16 to 14 AWG
Country of OriginUS
Dimensions0.87 in L x 0.3 in W
FinishElectro Plated Tin
ManufacturerThomas & Betts
MaterialBrass/Copper
Series250
Temperature Rating105 deg C
TypeInsulated
Type / StyleInsulated
Voltage Rating600 VAC
Documents
Features
Nylon insulationUnique construction of the female disconnect offers long term dependabilityFunnel entry insulators enable easier inserting of wire into barrelBrazed seam serrated barrel provides maximum tensile strengthSuitable for use with ERG4001, WT112M toolsColor coded for easy installation
Specifications
0.163 in Max Insulation
Thomas & Betts Sta-Kon® RB14-250FP 250 Insulated Piggy Back Disconnect, 16 to 14 AWG Conductor, Brass/Copper, Blue
