Sta-Kon 14RB-251T
Thomas & Betts Sta-Kon® 14RB-251T 250 Insulated Male Tab, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass/Copper, Blue
Sta-Kon 14RB-251T
Thomas & Betts Sta-Kon® 14RB-251T 250 Insulated Male Tab, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass/Copper, BlueIn Stock: 250More Info
|
In Stock: 250More Info
|
Product Description
Sta-Kon® Male Tab, Insulated, Series: 250, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Crimp Terminal, 300 VAC, 0.03 in THK Stock, 0.2 in Dia Maximum Nylon/Polyamide Insulation, 105 deg C, Brass/Copper, Blue, Tin Electro-Plated, 1.13 in L x 0.45 in W
Attributes
Documents
Features
Specifications
Attributes
Barrel TypeBrazed Seam
ColorBlue
Conductor size16 to 14 AWG
Country of OriginUS
Dimensions1.13 in L x 0.45 in W
FinishElectro Plated Tin
ManufacturerThomas & Betts
MaterialBrass
Series250
Tab Size0.25 in W x 0.032 in THK
Temperature Rating105 deg C
Terminal TypeCrimp
TypeInsulated
Type / StyleInsulated
Voltage Rating300 VAC
Documents
Features
Brazed seam serrated barrel provides maximum tensile strength
Specifications
0.2 in Maximum Insulation, 0.03 in Stock
Thomas & Betts Sta-Kon® 14RB-251T 250 Insulated Male Tab, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass/Copper, Blue
