Sta-Kon 14RB-250F
Thomas & Betts Sta-Kon® 14RB-250F Female Disconnect, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass, Blue, Insulated
Sta-Kon 14RB-250F
Thomas & Betts Sta-Kon® 14RB-250F Female Disconnect, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass, Blue, InsulatedIn Stock: 100More Info
|
In Stock: 100More Info
|
Product Description
Sta-Kon® Female Disconnect, Series: 250, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Crimp Terminal, 600 VAC, 0.17 in Dia Maximum Insulation, 0.03 in THK Stock, 105 deg C, Brass, Blue, Electroplated Tin, 0.96 in L x 0.29 in W, Insulated: Insulated
Attributes
Documents
Features
Specifications
Attributes
Barrel TypeBrazed Seam
ColorBlue
Conductor size16 to 14 AWG
Country of OriginUS
Dimensions0.96 in L x 0.29 in W
FinishElectroplated Tin
InsulatedInsulated
ManufacturerThomas & Betts
MaterialBrass
Series250
Tab Size0.25 in W x 0.032 in THK
Temperature Rating105 deg C
Terminal TypeCrimp
Type / StyleDisconnects
Voltage Rating600 VAC
Documents
Features
Vinyl insulatedUnique construction of the female disconnect offers long term dependabilityFunnel entry insulators enable easier inserting of wire into barrelBrazed seam serrated barrel provides maximum tensile strengthSuitable for use with WT145C, WT2000, WT112M, ERG4001, ERG4003 toolsColor-coded for easy installation
Specifications
0.17 in Dia Maximum Insulation, 0.03 in THK Stock
Thomas & Betts Sta-Kon® 14RB-250F Female Disconnect, 16 to 14 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass, Blue, Insulated
