Sta-Kon 10RC-14
Thomas & Betts Sta-Kon® 10RC-14 RC Series Insulated Ring Terminal, 12 to 10 AWG Conductor, 1.16 in L, Brazed Seam Barrel, Copper, Yellow
Sta-Kon 10RC-14
Thomas & Betts Sta-Kon® 10RC-14 RC Series Insulated Ring Terminal, 12 to 10 AWG Conductor, 1.16 in L, Brazed Seam Barrel, Copper, YellowIn Stock: 200More Info
|
BrandSta-Kon
MFG #10RC-14
Werner Part #63444
UPC786210800462
In Stock: 200More Info
|
BrandSta-Kon
MFG #10RC-14
Werner Part #63444
UPC786210800462
Product Description
Sta-Kon® Ring Terminal, Insulated, Series: RC Series, 12 to 10 AWG Conductor, 1/4 in Stud, 1.16 in Length, Brazed Seam Barrel, Ring Tongue, 0.5 in W x 0.04 in THK Tongue, 600 VAC, 0.21 in Dia Maximum Insulation, 0.27 in Clearance, Vinyl Insulation, 105 deg C, Copper, Tin Coated, Yellow
Attributes
Documents
Features
Specifications
Attributes
Barrel TypeBrazed Seam
ColorYellow
Conductor size12 to 10 AWG
Country of OriginUS
FinishTiN Coated
ManufacturerThomas & Betts
MaterialCopper
SeriesRC Series
Temperature Rating105 deg C
Tongue Size0.5 in W x 0.04 in THK
Tongue TypeRing
TypeInsulated
Type / StyleInsulated
Voltage Rating600 VAC
Documents
Features
Terminals are Self-insulated with a PVC insulation sleeve of extra length to give protection and relieve bending stress at wire flex pointBrazed seam barrel that is serrated to obtain high pullout valueMade of copper and has electro-tin plating for corrosion-resistance50 pieces/pack
Specifications
0.21 in Dia Maximum Insulation, 0.27 in Clearance, Vinyl Insulation
Thomas & Betts Sta-Kon® 10RC-14 RC Series Insulated Ring Terminal, 12 to 10 AWG Conductor, 1.16 in L, Brazed Seam Barrel, Copper, Yellow
