Hubbell Wiring Device - Kellems L715P
Hubbell Wiring Device-Kellems Twist-Lock® L715P Grounding Standard Sized Locking Male Plug, 277 VAC, 15 A, 2 Poles, 3 Wires, Black
Hubbell Wiring Device - Kellems L715P
Hubbell Wiring Device-Kellems Twist-Lock® L715P Grounding Standard Sized Locking Male Plug, 277 VAC, 15 A, 2 Poles, 3 Wires, BlackIn Stock: 155More Info
|
In Stock: 155More Info
|
Product Description
Hubbell® Pro™ locking devices provide a safe disconnect solution between an equipment load and a power source. These devices incorporate a locking interface that is engaged and disengaged simply by rotating the device assuring a safe and reliable electrical connection.
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating15
ColorBlack
Country of OriginCN
GradeCommercial/Industrial
GTIN00783585835723
ManufacturerHubbell
MaterialComposite
NEMA RatingL7-15P
Number of Poles2
Number of Wires3
SeriesGrounding Standard Sized
Temperature Rating-40 to 60 deg C
Terminal TypeScrew
Type1-Phase Grounding Standard Sized Cord Mount
Type / StyleGrounding Standard Sized
Voltage Rating277 VAC
Documents
Features
- Visible NEMA ratings
- Captive assembly screws
- Supertough® nylon body
- Impact modified nylon blade/contact holder
- Brass contacts/blade
- Withstands 3500 VAC per UL 498 dielectric voltage
- 600 VAC or 250 VDC maximum working voltage
- Maximum 30 deg C temperature rise at full rated current after 50 cycles overload at 150% rated current for either AC or DC applications per UL 498
- Minimum 4.8 times rated current for 100 cycles overload
- Terminals identified in accordance with UL 498 (brass, white, green)
- 18 to 8 AWG flexible cord
- Ratings and NEMA identification are permanently marked on device
- Indoor dry unless protected by additional means
- 14 to 12 AWG wire
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL Listed|CSA Certified
