Decora Plus 16352-W
Leviton® Decora® Plus 16352-W Heavy Duty Self Grounding Straight Blade Duplex Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, White
Decora Plus 16352-W
Leviton® Decora® Plus 16352-W Heavy Duty Self Grounding Straight Blade Duplex Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, WhiteIn Stock: 98More Info
|
BrandDecora Plus
MFG #16352-W
Werner Part #1052673
UPC078477819722
In Stock: 98More Info
|
BrandDecora Plus
MFG #16352-W
Werner Part #1052673
UPC078477819722
Product Description
Decora® Plus Straight Blade Duplex Receptacle, Heavy Duty Self Grounding, 125 VAC, 20 A, 1 hp, 2 Pole, 3 Wires, NEMA 5-20R NEMA, Commercial Grade, NEMA WD-1/WD-6 Enclosure, -40 to 60 deg C, Back/Side Wired Terminal, Thermoplastic, White, 4.06 in H x 1.31 in W x 1.14 in D Dimensions
Attributes
Documents
Features
Specifications
Attributes
Amperage Rating20
ColorWhite
Country of OriginMX
Dimensions4.06 in H x 1.31 in W x 1.14 in D
Enclosure TypeNEMA WD-1/WD-6
GradeCommercial
Horsepower1 hp
ManufacturerLeviton
MaterialThermoplastic
NEMA RatingNEMA 5-20R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
TypeHeavy Duty Self Grounding
Type / StyleHeavy Duty Self Grounding
Voltage Rating125 VAC
Documents
Features
Back wire and side wire terminal optionsHeavy gauge locked-in wraparound strapBack wire terminals accept up to no 10 AWG copper or copper clad wire, solid or strandedBrass staked on self-grounding clipHeavy duty triple-wipe brass contacts for long service lifeImpact-resistant thermoplastic construction
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI C-73|CSA C22.2 No. 42 File No. LR-406|NOM 057|UL 498 File No. E13399|UL 94 Flammability Rating
Leviton® Decora® Plus 16352-W Heavy Duty Self Grounding Straight Blade Duplex Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, White
